Carbonated Soft Drink Filling Machine
The carbonated drink filling machine is dedicated automatic equipment for carbonated beverages, sparkling water and soda water. Adopting low-temperature isobaric filling technology, it avoids CO₂ overflow and bubble loss to stabilize gas content and pure taste. Integrated with bottle washing, isobaric filling and capping, it operates in closed low-temperature state with high filling accuracy, solving common problems such as overflow, insufficient gas and poor taste of carbonated drinks.
Core Features
What this machine is built to handle.
Carbonated Soft Drink Filling Machine is part of the Filling Machine scope. It can be configured with upstream and downstream equipment according to product type, package format, target capacity and site layout.
Fully closed operation, low gas loss
Precise stable filling, no overflow
Intelligent temp control, real-time adjust
Application
- Suitable for the filling production of all carbonated beverages such as cola, soda, sparkling water, soda water, carbonated fruity drinks and carbonated functional drinks, adapting to various PET bottled carbonated beverage production lines.
Advantage
- 1. Special isobaric gas locking technology maximizes beverage bubble retention, and the finished product taste is consistent with the original liquid;
- 2. Completely solve the problems of overflow, gas escape and uneven capacity in carbonated beverage filling with high finished product qualification rate;
- 3. Automatic integrated operation with high production efficiency, suitable for large-scale mass production;
- 4. Low-temperature filling technology inhibits bacterial growth and extends beverage shelf life;
- 5. Suitable for various carbonated beverages with strong versatility and high equipment utilization rate.
Product Details
- Automatic bottle washing machine, isobaric filling host, low-temperature refrigeration system, pressure stabilizing system, automatic capping machine, bottle cap sorting system, conveying transmission system, intelligent electric control system, CIP cleaning system.
Product Detail
| Model | DCGF 14-12-5 | DCGF 18-18-6 | DCGF 24-24-8 | DCGF 32-32-8 | DCGF 40-40-10 |
| Washing Heads | 14 | 18 | 24 | 32 | 40 |
| Filling Heads | 12 | 18 | 24 | 32 | 40 |
| Capping Heads | 5 | 6 | 8 | 8 | 10 |
| Output(BPH) | 2000 | 5000 | 7000 | 9000 | 12000 |
| Oversize(mm) | 2000×1800×2200 | 2400×2000×2300 | 3000×2600×2300 | 3800×3200×2400 | 4500×3800×2400 |
| Power(kw) | 2.2 | 3.5 | 3.8 | 5.5 | 7.5 |
Supporting Production Line
Equipment that usually connects with this product.
Use these related machines to shape a complete line from pretreatment and filling through labeling, packaging and end-of-line handling.
Filling Machine
Bottled Water Filling Machine
The bottled water filling machine is an integrated fully automatic device specially designed for PET bottled purified water, mineral water and mountain spring water, integrating bottle washing, filling and capping. Adopting gravity atmospheric filling technology, it delivers stable and accurate filling without overflow or splash. With sanitary-grade design for sterile water quality, it adapts to multi-spec bottled water mass production and acts as core equipment for bottled water production lines.
Filling Machine
Hot Filling Machine
The hot filling machine is customized for heat-sensitive beverages including juice, tea drinks, pulp and herbal drinks. It adopts 85-95℃ high-temperature filling and sterilization technology to finish material and bottle sterilization synchronously without secondary sterilization. Integrating bottle washing, high-temperature filling, inverted sterilization and cooling, it eliminates bacteria and mildew, avoids deterioration and greatly extends the shelf life of normal-temperature beverages.
Filling Machine
Large Barrel Water Filling Machine
The barreled water filling machine, core equipment for barreled water production, has two models for reusable PC barrels and disposable barrels respectively. The reusable barrel model realizes thorough cleaning and disinfection via cap pulling, internal and external brushing and multi-stage flushing. The disposable model simplifies procedures with only rinsing, sterile filling and capping. Made of food-grade 304 stainless steel and equipped with PLC automatic control, it supports mainstream specifications of 3L, 5L, 10L and 18.9L, meeting commercial and household barreled water production needs.
Factory & After-sales Service
Built as a project, supported after delivery.
GTIG beverage machinery work is organized around complete-line planning, equipment coordination, export delivery and practical after-sales support. Share the product, package, capacity and plant condition so the team can prepare a matched configuration.
- Complete-line equipment coordination
- Factory production and delivery support
- Installation and commissioning guidance
- Spare parts and after-sales response
Send us your production target.
Ask for a Carbonated Soft Drink Filling Machine configuration with the supporting equipment, process route and line layout that fit your project.
